- Pressure-free surface
- Eliminates numbness
- Certified back friendly
The most fun you’ve ever had in the city or on tour – you can not be more comfortable than with the unique Ergon CORE 3D® saddle technology found on the SC Core. Vibrations and shocks? The ergonomic core simply absorbs them. Back problems? Not with this saddle. Three seals of approval attest to the back-friendly effectiveness. Feelings of numbness? Prevented by the relief channel specially developed for men. That’s our Pain-Free Support Formula and your feel good guarantee on the bike!
Specifications:
Use: City, E-City
Size: S/M
Colour: Black
Technology: CORE 3D®
Ergonomic Core: BASF Infinergy® (E-TPU / Closed Cell Particle Foam)
Shell: Nylon Composite
Rail: Light FeC Steel
Cover: Microfiber
Padding: Orthopedic Comfort Foam
Gender: men specific
Max. load: 140 kg
CORE 3D®: INGENIOUS CONCEPT AND DESIGN – The floating ergonomic core saddle
While you pedal, your weight is shifted back and forth to the left and right sit bones, resulting in pressure and discomfort. Ergon CORE 3D® reduces this pressure due to the special and unique material properties of the ergonomic core. The bike saddle is allowed to adapt to the pelvis with every pedal stroke resulting in an enormous gain in comfort.
INNOVATIVE INFINERGY®–Cycling on clouds
BASF’s innovative Infinergy® material sets new standards in suspension and damping on the bike. The elastic saddle core supports the natural pelvic movements with every pedal stroke, absorbs road shocks and is easy on the lower back. When pressure is released, the Ergon Core, which consists of thousands of foam particles, returns to its original shape in a flash – even under continuous load. Leading manufacturers of performance running shoes also use this E-TPU foam worldwide with great success.
THE ADVANTAGES OF TWIN SHELL–Ergon CORE 3D® vs. standard saddle
The revolutionary CORE 3D® saddle construction with twin shell technology takes comfort to a whole new level. In a conventional saddle, there is only one saddle shell. This single shell carries the load of the rider and must therefore be very rigid. The Ergon SC Core, on the other hand, has two shells. A majority of rider weight is supported by the lower stiffer shell. On the upper flexible shell lies the cushion and sitting surface. In between the two shells is the floating ergonomic core made of Infinergy®, which isolates road shock, dampens vibrations, supports pelvic movements when pedaling and noticeably takes pressure off the sit bones.
THE TWIN SHELL AND INNER CORE DAMPER–Support that follows your pedal stroke
The view below of the SC Core Evo shows the entire saddle surface – the high-performance elastomer damper decouples the two saddle shells from each other. This sandwich construction with elastic core allows the saddle to follow the natural pedaling movements more ergonomically in all three directions. Unevenness of the riding surface and vibrations are efficiently filtered out thanks to Ergon CORE 3D®.
ORTHOPEDIC FOAM–Comfortable and durable
The padding of the SC Core is made of orthopedic comfort foam, which we have designed for fitness bikes, e-bikes and touring bikes. The foam is supportive, soft, but does not collapse. In addition to the foam, specific gel pad inlays offer even more comfort under the sitting area. With this saddle, it is not absolutely necessary to wear cycling shorts. The saddle is covered with robust microfiber to prevent abrasions and maintain the durability of the saddle.
Minimizing Saddle Discomfort
When cycling, a majority of your body weight rests on the small saddle surface. If body weight is not distributed evenly to the bony structures, unnecessary pressures are then distributed to the sensitive soft tissue areas. A relief channel helps, but is not the only important factor to overall saddle comfort.
For an ergonomic distribution of pressure, the correlations between the sit bone distance and sitting angle must be taken into account. An ergonomic bicycle saddle should have sufficient contact surface, but still allow the thighs to move freely. Furthermore, cycling is not static. Pedaling uphill, the rider intuitively slides in the direction of the saddle nose to shift the body’s center of gravity forward. The reverse is true when going downhill.
Ergon takes all of this into account in the development of each saddle. We develop specific saddle models both for the everyday cyclist as well as professionals. Our saddles are available in different widths, are designed for dynamic sitting, are completely step-free and allow through their anatomical shape comfort in all riding positions.
Specific Saddles For Men And Women
When it comes to saddle contact points and relief areas, men and women are anatomically very different. Any incorrect pressure distribution in this area often leads to feelings of numbness and discomfort. Men experience this more towards the back of the saddle and women, more towards the front of the saddle. Through extensive research and development, two distinctly different designs were born. The two distinctly different designs share the common goal of maximum comfort.
Certified back friendly: Saddle with three seals of approval
Back pain is the number one ailment, which can quickly spoil the enjoyment of cycling. In an intensive testing process by an interdisciplinary panel of experts consisting of doctors, orthopedists and physiotherapists, the back-friendly effect of the CORE 3D® saddle principle was certified with three quality predicates: the AGR Seal of Approval of the „Aktion Gesunder Rücken“ (Healthy Back Campaign), the IGR Seal of the „Institut für Gesundheit und Ergonomie“ (Institute for Health and Ergonomics) and the „Formel Froböse“ quality seal.
The correct size
The shape and size of the saddle must match the sit bone width of the rider to maximize comfort and enjoyment. The pelvic bone has a unique V-shape and the saddle must offer the sit bones a large contact surface with the ability to meet the demand of different sitting positions. Various saddle widths are offered so that the usable seat surface corresponds to the rider’s unique sit bone width. The more forward and aggressive the rider sits, the further forward the sit bones contact the saddle.
